●Polyamide 66, UL 94V-2 flame-retardant housing.

●Provided contacts constructed from brass, zinc alloy or steel.

●Zinc-plated steel screws.

●Suitable for use with conventional ballasts and transformers.

●For use in lighting fixture, electrical appliances.

●Pre-cutting is available upon requested.

Item No:PA10B NW

Length:117.0mm

Width:18.7mm

Height:16.5mm

Pitch:10.0mm

Fixing Hole:3.25mm

Wiring Hole:3.45 ± 0.1mm

Raised Base:1.8mm

Screw:M3.0 x 7

Poles:12

Item No:PA10B NWC

Length:117.0mm

Width:18.7mm

Height:16.5mm

Pitch:10.0mm

Fixing Hole:3.25mm

Wiring Hole:3.45 ± 0.1mm

Raised Base:1.8mm

Screw:M3.0 x 7

Poles:12

Item No:PA10R

Length:117.2mm

Width:18.8mm

Height:16.0mm

Pitch:10.0mm

Fixing Hole:3.25mm

Wiring Hole:3.4 ± 0.1mm

Raised Base:2.4mm

Screw:M3.0 x 6.9

Poles:12

Item No:PA11-2

Length:17.3mm

Width:19.0mm

Height:19.2mm

Pitch:10.0mm

Raised Base:2.0mm

Screw:M3.0 x 7

Poles:2

Item No:PA11-3

Length:27.6mm

Width:19.0mm

Height:18.7mm

Pitch:10.0mm

Raised Base:2.0mm

Screw:M3.0 x 7

Poles:3
